Widely Used High-Efficiency Ambient Air Vaporizer for LN2, LOX and LAR

Usage: O2/CO2/N2/Ar2/LNG/LPG
Voltage: 220 V
Weight: 200 KG
Key Selling Points: long lasting
Machinery Test Report: Provided
Material: Aluminum alloy
Applicable Industries: Food & Beverage Shops
Place of Origin: China
Brand Name: Zhuoyue

Specification

Product name Industrial air heated vaporizer
Model Maximum evaporation
(Nm3/h)
Maximum working pressure (Mpa) Empty weight
(kg)
RM-50/25 50 2.3 100
RM-100/25 100 2.3 185
RM-150/25 150 2.3 245
RM-200/25 200 2.3 350
RM-500/25 500 2.3 6100
RM-1200/25 1200 2.3 2100
RM-1400/25 1400 2.3 2250
RM-2000/25 2000 2.3 3220
RM-4000/25 4000 2.3 5500

Model Working pressure
(Mpa)
Capacity
(Nm^3/h)
Temperature
(ºC)
Outer Size
(mm)
Weight
(kg)
Remark
QQLNG-500/1.6 1.6 500 -20ºC~50ºC 1705*1455*5415 1041 Finned tube Dia φ200
QQLNG-700/1.6 700 2471*1455*5415 1286
QQLNG-900/1.6 900 2471*1709*5765 1774
QQLNG-1000/1.6 1000 2471*1963*5765 1953
QQLNG-1500/1.6 1500 2217*2471*7265 3108
QQLNG-2000/1.6 2000 2497*2776*7515 4986
QQLNG-2500/1.6 2500 2217*5437*6165 5179
QQLNG-3000/1.6 3000 2217*5437*7265 6216

Main Technical Parameter

  • Working pressure: 0.8-35.0 Mpa;
  • Flow Rate : 50-16000 NM3/H ( If need more could use combined structure);
  • Medium: LOX,LIN, LAr,LCO2,LNG,LC2H4,LPG,ect.
  • Matrial: Aluminum Alloy
  • Standard: GB,ASME,PED(CE),CCS,CNNC,CASC

About Us

Founded in 2013,Hebei Excellence Gas Equipment Co.Ltd.covers an area of 33,000 square meters,has a registered capital of 51 million,and has more than 100 employees.

It is a manufacturer specializing in gas transmission and distribution equipment,a science and technology enterprise of Hebei Province,a high-tech certification enterprise,and a famous brand product enterprise of Hebei Province. ISO09001 international standardized quality management system certification unit, national gas equipment industry quality service reputation 3AAA level enterprise. Pressure element A gas pressure regulating device special equipment production license,pressure pipeline installation qualification.

Company main development and production of air temperature carburetor (evaporator),all kinds of low temperature storage tank (low temperature storage,miniature low temperature storage tank,Dewar bottle,LNG(relief) voltage regulator metering station(pry), LNG gasification pressure regulating equipment,low temperature filling pump,LPG equipment of LNG or CNG,LNG Marine LPG filling system SCADA system. Total more than 100 kinds of products,more than 2000 product specifications.Mainly serve metallurgy.mining,steel,energy. transportation,chemical,electronics and other fields. With strong technical research and development and manufacturing capacity,high-level engineering and technical personnel and highly skilled workers,advanced welding, processing and testing equipment,strong design,manufacturing,installation and debugging capacity,information management platform and simple management mode,stable product quality, 24 hours of after-sales service.

The company’s products are all over the country. with a number of listed companies have deep cooperation,and successfully exported to southeast Asia,the Middle East,Central Asia,Africa and Russia and other countries and regions.

Factory Workshop

factory

Packing & Delivery

Packing & Delivery

Certificate

Certificate

Inquiry
