Specification
|
Item |
Height |
Diameter |
Liquid inlet |
Gas outlet |
|
50 kg/h |
1200 |
φ 400 |
DN25 |
DN25 |
|
100 kg/h |
1360 |
φ 400 |
DN25 |
DN25 |
|
150 kg/h |
1360 |
φ 400 |
DN25 |
DN25 |
|
200 kg/h |
1540 |
φ 460 |
DN32 |
DN32 |
|
300 kg/h |
1723 |
φ 560 |
DN40 |
DN40 |
|
400 kg/h |
1723 |
φ 560 |
DN40 |
DN40 |
|
500 kg/h |
2220 |
φ 600 |
DN50 |
DN50 |
Technical parameter
|
Model |
Voltage |
Power |
Gasification capacity |
Work pressure |
Operating temperature |
|
ZYLPE-20 |
220 V |
2 KW |
20 kg/h |
1.76 Mpa |
≤60℃ |
|
ZYLPE-30 |
220 V |
3 KW |
30 kg/h |
1.76 Mpa |
≤60℃ |
|
ZYLPE-50 |
380 V |
7.5 KW |
50 kg/h |
1.76 Mpa |
≤60℃ |
|
ZYLPE-100 |
380 V |
15 KW |
100 kg/h |
1.76 Mpa |
≤60℃ |
|
ZYLPE-150 |
380 V |
18 KW |
150 kg/h |
1.76 Mpa |
≤60℃ |
|
ZYLPE-200 |
380 V |
30 KW |
200 kg/h |
1.76 Mpa |
≤60℃ |
|
ZYLPE-300 |
380 V |
45 KW |
300 kg/h |
1.76 Mpa |
≤60℃ |
|
ZYLPE-400 |
380 V |
54 KW |
400 kg/h |
1.76 Mpa |
≤60℃ |
|
ZYLPE-500 |
380 V |
68 KW |
500 kg/h |
1.76 Mpa |
≤60℃ |
Feature:
1. Electric water bath Vaporizer technology, safe, gasification energy from 20KG to 500KG per hour. Applicable to community residential and industrial and commercial gas.
2. Both the electric control device and the electric heater adopt the explosion-proof design, and the explosion-proof grade is Ex DIIBT4.
3. The gasifier has a solid structure and anti-corrosion performance.
4. The electric control box and the vaporizer are integrated into one structure, which saves space and is convenient and convenient.
5. The detection pressure of the gasifier is 3.3MPa (33kg/cm2), and the safety rated pressure is: 1.76MPa (17.6kg/cm2).
6. Explosion-proof solenoid valve, the solenoid valve will automatically close when the gas outlet passes through the liquid.
7. The safety pressure relief valve can automatically discharge the excess pressure gas and then close it automatically.
8. The secondary electronic temperature controller can automatically adjust the water temperature of 60-70 degrees, and the air supply is stable.
Notice:
1. Piping: Check carefully whether the liquid phase and gas phase outlets are connected to the corresponding pipes.
2. Water injection: Add pure distilled water or pure water without impurities to the water injection point marked on the furnace body of the gasifier until the bottom of the furnace body overflows.
3. Power supply: This furnace type does not have an electric control box. Open the anti-riot cover on the furnace body directly, enter the three-phase four-wire power line from the wiring port on the furnace body, and connect the three-phase power supply to the A marked on the terminal board. , B, C, N is the zero line.
4. The thermostats, relays, heating tubes, etc. in the cover have been adjusted before leaving the factory, and non-personnel are not allowed to adjust them at will.
5. Close and tighten the open explosion-proof compartment cover.
